Vortex Flowmeter PCL-V10

Product Overview

The PCL-V10 series vortex flowmeter is a fully intelligent flowmeter developed by combining advanced domestic and foreign technologies. It has the characteristics of simple structure, low power consumption, small resistance loss, stable operation, long durability, and easy installation.

The PCL-V10 series vortex flowmeter pays attention to every step in the process of design, material selection, process manufacturing, production assembly, and factory testing; The product has a variety of output signal forms, including standard analog signals and standard digital signal output signals, which are easy to use with digital systems such as computers and se- condary instruments, achieving the intelligence,standard-

ization, and universality of the product.

Features

 Advanced circuit design, with both low-power amplifier and current output signal functions on the circuit board

The product measurement range is relatively wide

Output signal 4mA~20mA two-wire current signal corresponding to flow rate

Display both cumulative and instantaneous traffic simultaneously

With five stage nonlinear correction, small signal removal, and free damping time setting function

Fully universal design, small overall size, and compact structure. Suitable for flow measurement of liquid and gas media with different diameters

New digital filtering and correction functions make flow measurement more accurate and reliable

Advanced humanized design, easy to operate and use



Application

The measurement and control of compressed air and general gases (such as oxygen, nitrogen, hydrogen, natural gas, coal gas, etc.), water, and liquids (such as water, gasoline, alcohol, benzene, etc.) in industries such as petroleum, chemical, metallurgy, heating, textile, and papermaking.




Product Parameters

Performance parameter


Accuracy

Liquid; ±1.0%

Gas; ±1.5%

Pipe diameter

DN15DN300

Rated pressure

GB; PN2.5, PN6, PN16, PN25, PN40, PN63, PN100, PN160, PN250

ANSI; CLASS 150, CLASS 300, CLASS 600, CLASS 900

DIN; PN10, PN16, PN25, PN40, PN63

JIS; 5K,10K, 16K, 20K, 30K, 40K, 63K

Special pressure: customizable

Medium temperature

Ordinary temperature: -40℃80℃

Moderate temperature: -40℃250℃

High temperature: -40℃350℃

Body material

Stainless steel 304 (conventional)

Range ratio

1:10(Theoretical value)

Flow rate range

Liquid (water): 0.7m/s7m/s

Gas: 5m/s70m/s

Steam: 4m/s70m/s

Reynolds number

1.5×1044×106

Drag coefficient

Cd≤2.4

Power supply and output signal

24VDC: pulse output signal (without display), 4-20mA/pulse (with display), 4-20mA/pulse/485 (with display)

Battery powered: No output signal (with display)

Protection grade

IP65

Ambient temperature

Non explosion-proof locations: -40 ℃~55 ℃; Explosion proof location: -20 ℃~55 ℃

Explosion proof

Explosion proof (24VDC) certificate number: CNEx22.4919X mark: Ex db IIC T6 Gb

Overall dimension

Outline structure

                           Dimension                       Unit:mm

PCL-V10J Clamping Vortex Flowmeter








In the above figure, A represents the length of the flow meter measuring tube; B represents the diameter of the flowmeter interface; C represents the length between the top of the meter head and the bottom of the pipeline interface.

The outer dimensions of the flange clamped vortex flowmeter are shown in Table 1.
